Computer - 4U Size - Server - Rackmount - 4U

HT 404XE STD-Ay

Get first-class performance across a broad range of applications with HT 404XE STD Maritime Rack Server/Computer.

4U Size

Server

Send Request

Description

Specifications

Typenumber (Long):	HT 404XE STD-Ay
Installed Operating System Options:	None or Option Dependent
Storage Options:	3,5" SATA, 7200 RPM, 32MB Buffer HDD (Option Dependent)
Processor / CPU and FSB Speed Options:	1 x Intel® Xeon® 64Bit, Socket 604, 3.0GHz, 800MHz FSB or Option Dependent
Memory Options:	2 x 1GB Dual Channel DDR2 800/667MHz SDRAM, 240-pin DIMM
System+Graphics Chipset / Connectors:	Intel® E7525 (Tumwater) and Matrox DualHead® P690 128MB, PCIe x16 Graphics Card with 2 x 29P (female) DVI-I
Max Resolution / Max Hz:	2048 x 1536 @ 85Hz
BIOS:	Phoenix 8MB Eeprom Flash. On-board BIOS Speaker.
PCI Slots / PCIe Slots:	1 x PCIe 16x (Used by Matrox DualHead® P690) + 1 x PCIe 1x + 1 x 64bit 133MHz PCI-x (3.3v) + 1 x 64bit 100MHz PCI-x (3.3v) + 1 x 32bit 33MHz PCI (5v)
Media Drive(s):	1 x DVD-RW/CD-RW Dual Recorder / Player
LPT / Parallel Port:	1 x Bi-Directional Centronics with ECP/EPP
Serial Port(s):	2 x DB9M RS-232 Fast Uart 16550
Ethernet Port(s):	1 x RJ45 10/100/1000Mbps Intel® 82545GM
USB Port(s):	4 x USB2.0 Type A (rear) + 1 x USB2.0 Type A (front)
Keyboard and Mouse Ports (PS/2):	1 x PS/2 Keyboard + 1 x PS/2 Mouse
Audio Ports:	3 x 3.5mm Jacks (LINE IN/LINE OUT/MIC IN), AC97 6 channel
Buzzer:	None
Power Manager and Monitoring:	ACPI/APM
Power Specifications and Consumption:	STD AC IEC - 115/230VAC - 47-63Hz (500W Redundant Autorange) AC: Operating (TYP): TBD
Digital I/O Connectors:	None
Key Features:	High Performance Server Secure Redundant Power Supply Heavy-duty steel 4U Rackmount chassis
Product Dimensions and Weight:	W:482.50 [19.00"] x H:177.80 [7.00"] x D:506.50 [19.94"] mm [inch] 4U Rack size in height. Approx 25.5kg / 56.1lbs
Product Carton Size and Weight:	L:610.00 [24.02"] x W:58.00 [2.28"] x H:300.00 [11.81"] mm [inch] 21.0kg / 46.2lbs
User Controls / Activity:	On/Off Push Button, Reset Button, Power LED / 4 x HDD LED, 1 x Network LED
Factory Options:	• Additional 1 x Intel® xeon 64Bit, 3.0GHz CPU • Up to 32GB DDR266/333Mhz Registered ECC MEM • 1 x Fiber Fast Network Card with ST Connector • Raid Controller, Modes 0,1,4,5,10 supported - Max 4 ports • Up to 4 x 500GB 3,5" SATA, 7200 RPM, 32MB Buffer HDD possible
Accessories:	USB Cable 1m (Type A to Chassis mount receptacle)
Capabilities / Prepared for:	N/A
Operating Temperature:	-15.0°C / 5.0°F to 55.0°C / 131.0°F, Humidity up to 95%
Storage Temperature:	-20.0°C / -4.0°F to 60.0°C / 140.0°F, Humidity up to 95%
Compass Safe Distance:	Standard: 300.00 [118.11"] - Steering: 220.00 [86.61"] cm [inch]
Type Approval, Testing and Certificates:	EN60945 4th (IEC945 4th), CENELEC/SC 31-7: EN 50016 Ex-P, IACS E10, NK - Nippon Kaiji Kyokai, GL - Germanischer Lloyd, DNV - Det Norske Veritas, ABS - American Bureau of Shipping, BV - Bureau Veritas, LRS - Lloyd's Register

Specifications last updated: January 19, 2026 @ 13:13
