HM 24T25 XVD

Overview

Monitor - Widescreen - 4K UHD - LED - TEMPEST Certified - 23.8 inch - MIL Qualified

HM 24T25 XVD

Hatteland Technology's Xtreme rugged Military range of multi vision monitors (XVD) are designed to provide high-quality 4K UHD (3840 x 2160) resolution video and graphics performance into modern military/naval platforms.

icon
Widescreen
icon
High-res
icon
LED-backlit
icon
EN60945
icon
TEMPEST Certified
Send Request
Description

Monitor - TEMPEST Certified

The XVD is designed to meet the requirements of 50g shock eliminating the need for shock isolation in the rack or console, as well as MIL-STD-167-1A, MIL-STD-461F&G, and MIL-STD-810F&G. By combining the superior 4K UHD picture quality with Optical Bonding technology with its new, shock resistant chassis Hatteland Technology has raised the standard for affordable rugged monitors.

The clarity and enhanced color and image quality produced by our proprietary Optical Bonding technology makes the XVD ideal for information-intensive applications. With our fully-adjustable backlight system (0-100%), the XVD is suitable for round-the-clock use, day or night.

The cutting edge high definition LED monitor technology used, with its high quality brightness and contrast, in combination with aspect ratio of 16:9 enables the presentation of large amounts of data onto one screen. Flexible I/O options supporting both analog and digital inputs, AC and DC power (Multipower) connection makes the XVD a perfect choice for the versatile demands of modern military/ naval system designs
Specifications
Typenumber (Long): HM 24T25 XVD-MAT-0OVA
TFT Technology: LED Backlight Technology, Optical Bonding Technology, TFT active-matrix liquid crystal panel, RGB vertical stripe, IPS (In-plane Switching) LCD Technology
Viewable Size and Active Area: 23.8 inch - 527.04 [20.75"] (H) x 296.46 [11.67"] (V) mm [inch]
Native Resolution and Pixel Pitch: 3840 x 2160 (UHD) - 0.13725 (H) x 0.13725 (V) mm
Aspect Ratio and Response Time: 16:9 - 14 ms (typical), "gray" to "gray"
Light Intensity and Contrast Ratio: 221 cd/m² (typ) - 1000:1 (typ)
View Angle and Max Colors: 89 deg. (up/down/left/right) - 16.7 million
Optimal Resolution and Hz: 3840 x 2160 @ 60 Hz
Detectable Resolutions: VGA (640 x 350) to UHD (3840 x 2160)
Composite Video Input(s): None
Supported Video Signals: None
Product Features: TEMPEST Certified, Optical bonding mesh glass, Qualified for shock, vibration & EMI, Fully adjustable backlight (0-100%), PIP (Picture-in-Picture), Serial Communication (SCOM) Interface, Toughened Glass, Suitable for C4i, navigation and automation
Power Specifications and Consumption: Multi-Power: 100-240V AC - 50/60Hz + 24 VDC
Operating Standard: 32W (Typ) - 50W (Max)
User Controls and Activity: Tactile Display Controls (TDC) on front bezel:
• Power LED, Mode Status Indicators LED (Service, Alarm)
• Power On/Off button, On Screen Display control (OSD)* button
• Up/Down OSD Navigation / Hotkey buttons
• +/- Brightness Control Buttons
*OSD Key Codes: 321=Get access to OSD, 362=Advanced Mode
Connectors: • DVI-D Input: 1 x 24p DVI (female) NOTE: Not approved for TEMPEST. Connector blocked (hatch cover) by factory default.
• VGA Input: 1 x 15p HD D-SUB (female) - Max 1920x1200@60Hz. NOTE: Not approved for TEMPEST. Connector blocked (hatch cover) by factory default.
• HDMI 2.0 Input: 1 x 19p HDMI (female) - Max 3840x2160@60Hz
• DP 1.2 Input: 1 x 20p DisplayPort (female) - Max 3840x2160@60Hz
• SCOM RS-422/485: 1 x 5-pin Terminal Block 3.81 non-isolated
• SCOM Ethernet: 1 x RJ45 Connector for Remote Control
• SCOM RS-232: 1 x 9p D-SUB (female) non-isolated
• SCOM USB: 1 x USB TYPE A Connector (female)
• User Interface: 1 x 9p D-SUB (male) - Potentiometer Analog Input, User Brightness (BRT), I2C and +5VDC & 12VDC OUT
• FW Update: 1 x USB TYPE A (female) for Firmware Update
• AC Power IN: 1 x Std IEC Inlet
• DC Power IN: 1 x 2-pin Terminal Block 5.08
Product Dimensions and Weight: W:630.00 [24.80] x H:425.00 [16.73] x D:81.00 [3.19] mm [inch]
Weight: Approx. 13.0kg / 28.6lbs
Product Carton Size and Weight: L:770.00 [30.31"] x W:195.00 [7.68"] x H:625.00 [24.61"] mm [inch] - 0.09 cbm
Weight: Approx. 16.0kg / 35.2lbs
Factory Options: None
Accessories: None
Capabilities - Prepared for: SDIP-27 Level B has been approved with the following configurations:
• HDMI 2.0 Input: 1 x 19p HDMI (female) using ART: C-HM/HM-6*
• DP 1.2 Input: 1 x 20p DisplayPort (female) using ART: VSD101004-1*
*1 pcs of each cable is included in delivery.
Operating Temperature: AC Model: -15.0°C / 5.0°F to +55.0°C / 131.0°F (MIL-STD 810F&G*)
DC Model: -15.0°C / 5.0°F to +55.0°C / 131.0°F (MIL-STD 810F&G*)
Humidity up to 95% at +55.0°C / 131.0°F (IEC 60945 4th)
*Designed to meet
Storage Temperature: Dry Heat: +70.0°C / 158.0°F (MIL-STD 810F&G*)
Cold: -40.0°C / -40.0°F (MIL-STD 810F&G*)
Humidity up to 95% at +55.0°C / 131.0°F (IEC 60945 4th)
*Designed to meet
IP Rating: Protection: IP66 front - IP22 rear (EN60529)
Compass Safe Distance: Standard: 95.00 [37.40"] - Steering: 70.00 [27.56"] cm [inch]
Type Approval, Testing and Certificates: IEC 60945 4th (EN 60945:2002), IACS E10, ABS - American Bureau of Shipping, EU RO MR - Mutual Recognition, CCS - China Classification Society, BV - Bureau Veritas, TEMPEST SDIP-27 Level B - TEMPEST certified by the Norwegian National Security Authority, KR - Korean Register of Shipping, LRS - Lloyd's Register of Shipping

Environmental Performance:
Shock: 30g & 50g/11ms, 50g/30ms (MIL-STD 810F&G*)
Rain (drip proof): MIL-STD-810F&G* - Console mounted
Salt Fog: MIL-STD-810F&G*
Vibration Testing: MIL-STD-167-1A*

EMI Testing:
MIL-STD 461F&G*, CE 101, CE 102, CS 101, CS 114, CS 116, RE101, RE102, RS101, RS103
*Designed to meet

Air Pressure Maximum Altitude: Operating: 4000m - Storage: 12912m
Air Pressure Maximum Altitude (Bonded): Operating: 3000m - Storage: 3000m
Specifications last updated: June 3, 2025 @ 10:20
Type Approvals
Downloads
Accessories

Latest Product Updates

Engineering Change Notifications (ECN):
28 Oct 2024
Changes packaging marking with UKCA symbol - all produc...

7 Aug 2023
Changes product marking - all products

News Stories:
11 Jun 2021
Product released to website
