Engineering Change Notification

Public | Finalized Published: 14 September 2022 - Reference: 12_2022_ECN

Chassis update and second SSD source added for HTS31470 models

To ensure continuous compliance to product safety, we have decided to implement a product design update for all products. Applicable for HTS31470-i7-AC Axxxxxx. See illustrations in attachements below.
HTS31470-i7-AC Axxxxxx

Notice: Customized models are ALSO affected by this Engineering Change Notification.

HTS31470-i7-AC Axxxxxx

Effective from:

Chassis changes: From next delivery.
SSD: Gradual implementation, starting during Q3 2022, depending on component availability.

Changes:

- Chassis ventilation holes changed to smaller rounded ones.
- HDD LED2 in front removed, not used or configured.
- 4 screws added to cover and brackets inside to reduce potential vibration
- Intel SSD S4520 storage device added as second source (primary source: Intel S4510).

Additional information:

All modifications tested and verified according to IEC 60945 / IACS-E10 and Hatteland Technology standard procedures.

No change of part number, New HW00 to HW01.
(HW code is seen as step in S/N, S/N = xxyyyy, where xx is HW code and yyyy is the runing number. Leading zeros is not printed).

Contact:

For further enquiries regarding this Engineering Change Notification, please contact Support at Hatteland Technology AS.

Attachments:

Previous model (Technical Drawing) (580.7kb)
a012666_hts31470-xx-xx_yxxxxxx_hw00.pdf Updated model (Technical Drawing) (577.8kb)
a013121_hts31470-xx-xx_yxxxxxx.pdf Ventilation holes rear changed (9.3kb)
hts31470__con.jpg HDD LED2 in front removed (5.9kb)

Matching products online:

HTS31470-i7-AC Axxxxxx

Implemented by:

________________________________

Frode Grindheim
VP Products
Hatteland Technology AS

Read and Understood by:

________________________________

(Your name)
(Your company)

Last revised: 28 August 2024
