Product Notifications

Engineering Change Notification

Public | Finalized Published: 30 June 2017 - Reference: 21_2017_ECN

GDCX - Change of ECDIS and +/- symbol color

Hatteland Display hereby informs about changes for Glass Display Control (GDCX) - User Controls:

Series X Generation 2 (G2) - Maritime Multi Display (MMD):
24 and 26 inch displays.

Multi Vision Display (MVD):
32 inch display, 55 inch Chart & Planning Table and 55 inch Wall Mount display.
HD 24T22 xxD-xxx-xxxx (24 inch)
HD 26T22 xxD-xxx-xxxx (26 inch)
HD 32T22 MVD-MAx-AxGx (32 inch)
HD 55T22 MVD-MAx-AOGx (55 inch - Wall Mount Model)
HD 55T22 MVD-AAx-TOGP (55 inch - Chart & Planning Table Model)

Notice: Customized models are ALSO affected by this Engineering Change Notification.

Effective from:

1 August 2017. Gradual implementation.

Changes:

- Change backlight color of "ECDIS", "+" and "-" LEDs indication from Red to Orange (see illustration in attached links below).

Additional information:

Models delivered with this change will have "NXP" firmware Reference: "FW100002-0A15". Orange ECDIS color will be factory default for all Series X Generation 2 (G2) models (15 to 27 inch) as per this dated ECN.

Contact:

For further enquiries regarding this Engineering Change Notification, please contact Support at Hatteland Technology AS.

Attachments:

Current ECDIS symbol in RED color. (24.5kb)
old_gdc.jpg New ECDIS symbol changed to Orange color. (29.0kb)

Matching products online:

HD 55T22 MVD-AAx-TOGP
HD 55T22 MVD-MAx-AOGx
HD 32T22 MVD-MAx-AxGx
HD 26T22 MMD-xxx-Fxxx
HD 24T22 MMD-xxx-FHxx
HD 24T22 MMD-xxx-Fxxx

Implemented by:

________________________________

Frode Grindheim
VP Products
Hatteland Technology AS

Document sent to customers.

Reference: MAI/222449

Last revised: 28 August 2024
