Engineering Change Notification

Public | Finalized Published: 9 April 2018 - Reference: 05_2018_ECN

Touch Screen USB Cable - Contents of Package

Hatteland Display hereby informs about changes for the Touch Screen Cable which is included on shipments containing Display based products with Factory Mounted Touch Screen.
USB-8 (Current)
VSD100913-1 (New)

Notice: Customized models are ALSO affected by this Engineering Change Notification.

USB-8 (Current)

Effective from:

As per this dated document.

Changes:

- USB-8 changed to VSD100913-1.
- Cable color changed from Grey to Black.

Additional information:

Reason is qualification of second source. Function of new VSD100913-1 cable remains the same. Length of approx. 2meters remains unchanged. Connectors is TYPE A to TYPE A as before.

New cable has been tested and approved by Hatteland Display.

The following User Manuals will be updated (Contents of Package section):
INB101141-1, INB101141-2, INB100519-1, INB100535-2, INB101192-2, INB101283-1.

Contact:

For further enquiries regarding this Engineering Change Notification, please contact Support at Hatteland Technology AS.

Matching products online:

JH 23T14 MMD-xxx-Axxx
JH 22T11 MMD-xxx-Axxx
JH 20T17 MMD-xxx-Axxx
JH 19T14 STD-AA1-AAAA
JH 19T14 MMD-Mxx-Sxxx
JH 19T14 MMD-xxx-Axxx
JH 15T17 MMD-xxx-Axxx
HD 55T22 MVD-MAx-CORx
HD 55T22 MVD-MAx-COTx
HD 55T22 MVD-MAx-AOGx
HD 32T22 MVD-MAx-AxGx
HD 27T22 MMD-xxx-Fxxx
HD 26T22 MMD-xxx-Fxxx
HD 26T21 STD-xxx-Fxxx
HD 26T21 MMD-xxx-Fxxx
HD 24T22 MMD-xxx-FHxx
HD 24T22 MMD-xxx-Fxxx
HD 24T21 STD-xxx-Fxxx
HD 24T21 MMD-xxx-FHxx
HD 24T21 MMD-xxx-Fxxx
HD 19T22 MMD-xxx-FHxx
HD 19T22 MMD-xxx-Fxxx
HD 19T21 STD-xxx-Fxxx
HD 19T21 MMD-xxx-FHxx
HD 19T21 MMD-xxx-Fxxx
HD 17T22 MMD-xxx-FHxx
HD 17T22 MMD-xxx-Fxxx
HD 17T21 STD-xxx-Fxxx
HD 17T21 MMD-xxx-FHxx
HD 17T21 MMD-xxx-Fxxx
HD 15T22 MMD-xxx-FHxx
HD 15T22 MMD-xxx-Fxxx
HD 15T21 STD-xxx-Fxxx
HD 15T21 MMD-xxx-Fxxx
HD 13T21 STD-xxx-Fxxx
HD 12T21 STD-xxx-Fxxx
HD 12T21 MMD-xxx-Fxxx
HD 08T21 STD-xxx-Fxxx
HD 15T22 MMD-xxx-FHxx (HW00)

Implemented by:

________________________________

Frode Grindheim
VP Products
Hatteland Technology AS

Read and Understood by:

________________________________

(Your name)
(Your company)

Last revised: 28 August 2024
