JH 1702 MXP

Overview

CRT Monitor - Industrial - 17.0 inch

JH 1702 MXP

Send Request
Description

CRT Monitor

Specifications
Typenumber (Long): JH 1702 MXP
Picture Tube: 17" flat Square CRT, 41cm, 41cm usable square 0.28 mm Trio dot pitch Dot type black matrix. Medium-short persistence phosphor, dark bulb, glass with multi-layered anti-static coating
Input Signal: Video: Analog 0.7 Vp-p / 75 Ohms Positive
Sync: Separate Sync TTL Level
Horizontal sync: Positive/Negative
Vertical sync: Positive/Negative
Composite sync TTL Level: Positive/Negative
Sync. on green: (0.3 Vp-p) Negative
Display Colors Analog Input: Unlimited colors (depends on video card used)
Synchronization Range: Horizontal: 31 kHz to 82 kHz (Automatically)
Vertical: 55 Hz to 160 Hz (Automatically)
Resolutions: Horizontal: 1280 dots
Vertical: 1024 lines
Maximum Video Bandwidth: 140 MHz
Active Display Area (factory setting): Horizontal: 306 mm
Vertical: 230 mm
Active Display Area (full scan): Horizontal: 316 mm
Vertical: 237 mm
Power Supply: AC 220 - 240V, 50/60 Hz 1.3A
Power Consumption: 147 W
Input Signal Terminals: 15 pin mini D-SUB connector
User Controls and Adjustment Features: Power Switch/Degauss
Side Pincushion Control
Vertical Size Control
Horizontal Size Control
Vertical Position Control
Horizontal Position Control
Contrast Control
Brightness Control
Environmental Considerations: Operating: Temperature 0°C to +55°C, Humidity 30% to 80%
Storage: Temperature -20°C to +60°C, Humidity 10% to 90%
Factory Options: • Front
• Cabinet
• Brackets
• Touch Screen
Product Dimensions and Weight: 417 (W) x 433 (H) x 489 (D) mm
23.5 kg
Type Approval, Testing and Certificates: Based on E-10, IEC945 and classification society approvement:
ClassNK - Nippon Kaiji Kyokai, GL - Germanischer Lloyd, LRS - Lloyd's Register of Shipping, CE Classified
Specifications last updated: July 7, 2025 @ 11:10
Type Approvals
Downloads
Accessories

Latest Product Updates

End of Life Notifications (EOL):
24 Nov 1997
Product Obsolete

Obsolete
