HT 205P4
Computer - 2U Size - Rackmount - 2U
HT 205P4
Get first-class performance across a broad range of applications with HT 205P4 STD Maritime Rack Computer. Ideal for use in industrial and maritime environments where performance and reliability is important. Leading edge technology makes these computers the smart choice for all heavy applications.
2U Size

Computer - Rackmount
Brief Specifications:• Intel® Pentium®4 - 2.8GHz (Socket 478)
• Graphics SMI 712 (2D), 2MB Memory, Max 1024x768 @ 85Mhz
• 1 x 512MB RAM
• 1 x 80GB 2,5” HDD
• 1 x DVD-RW 48x (CD) / 16x (DVD R) / 6x (DVD-R DL) / 8x (DVD+R DL)
• 1 x 1,44MB 3,5” FDD
• 1 x 10/100/1000Mbps Gigabit LAN
• 3 x RS-232 Serial Ports
• 1 x Parallel port
• Standard PS/2 mini DIN connector and pin header for keyboard and mouse.
• Power supply 115/230V - 400W (Autorange)
Typenumber (Long): |
HT 205P4 STD-A1 |
Installed Operating System Options: |
None, please specify when ordering |
Storage Options: |
1 x 80GB 2.5" IDE HDD, 5400 RPM, 8MB Cache SATA150 Installed (Max 120GB possible) |
Processor / CPU and FSB Speed Options: |
1 x Intel® Pentium® 4 2.8GHz / Socket 478 / 800MHz FSB / 1MB L2 Cache |
Memory Options: |
4 x 184 Pin DIMM Sockets, 512MB Installed (1 slot used) (PC3200 DDR400) (Max 4GB possible) |
System+Graphics Chipset / Connectors: |
Intel® 875P / On-board SMI 712 (2D), 2MB Display Mem, Max 1024x768 @ 85 Hz 1 x DB15F |
Max Resolution / Max Hz: |
1024 x 768 / 85Hz |
BIOS: |
Award BIOS™ |
PCI Slots / PCIe Slots: |
1 x PCI2.3 Slots 32-bit, 3V and 5V Interface, Full Length Profile via Raiser Card |
Media Drive(s): |
1 x DVD/CD-RW Dual Layer Recorder/Player - 48x(CD) / 16x(DVD-R) / 6x(DVD-R DL) / 8x(DVD+R DL) FDD Controller: 1 x 1.44 MB 3.5" |
LPT / Parallel Port: |
1 x DB25F Bi-Directional Centronics with EPP/ECP mode |
Serial Port(s): |
3 x RS-232 16C550 Compatible, DB9M |
Ethernet Port(s): |
1 x 10/100/1000Mbps Intel® 82547GI Gigabit LAN - RJ-45 |
USB Port(s): |
6 x USB 2.0 Typr A (in back) |
Keyboard and Mouse Ports: |
1 x PS/2 Keyboard 1 x PS/2 Mouse |
Audio Ports: |
ICH5R built-in Sound Controller + AC97 Codec ALC650 (5.1 channels) Line In, Line Out, Mic In - 3 x JACKS |
Buzzer: |
None |
Power Manager and Monitoring: |
APM and ACPI |
Power Specifications and Consumption: |
115VAC/60Hz or 230VAC/50Hz - STD IEC Operating: TBD(TYP) - TBD (MAX) |
Digital I/O Connectors: |
None |
Key Features: |
2U Rackmount Chassis, Black Heavy-duty steel chassis with handles, Removable air filter, Dual lockable latch doors |
Product Dimensions and Weight: |
W:427.00 [16.81"] x H:88.50 [3.43"] x D:480.00 [18.90"] mm [inch] Approx 10kg / 22lbs |
Product Carton Size and Weight: |
N/A |
User Controls / Activity: |
Power On/Off Push Button, Power LED, HDD LED |
Factory Options: |
• Memory upgradeable to max 4GB • 2.5" Harddisk upgradeable to max 120GB • Bracket for additional comport (1 x RS232/422/485) (will occupy 1 PCI bracket area) - 1 x DB9M • Rail Kit |
Accessories: |
None |
Capabilities / Prepared for: |
N/A |
Operating Temperature: |
-15.0°C / 5.0°F to +55.0°C / 131.0°F, Humidity up to 95% |
Storage Temperature: |
-20.0°C / -4.0°F to +60.0°C / 140.0°F, Humidity up to 95% |
Compass Safe Distance: |
Standard: 155.00 [61.02"] - Steering: 115.00 [45.28"] cm [inch] |
Type Approval, Testing and Certificates: |
EN60945 4th (IEC945 4th), DNV - Det Norske Veritas, ABS - American Bureau of Shipping, IACS E-10, BV - Bureau Veritas, ClassNK - Nippon Kaiji Kyokai, GL - Germanischer Lloyd, LRS - Lloyd's Register of Shipping |
Specifications last updated: July 4, 2025 @ 08:44 |
